Unique features increase test efficiency and flexibility of R&S ATS1500C automotive radar test chamber from Rohde & Schwarz

The R&S ATS1500C antenna test system from Rohde & Schwarz offers a new temperature test option and a new feed antenna. These additional features enable temperature-controlled measurements in a wide temperature range as well as parallel access to both polarizations, increasing test efficiency and flexibility. The solution will be shown at EuMW from September 27 to 29, 2022 at booth D18 of the Milano Convention Centre.

The movable R&S ATS1500C is a compact antenna test range (CATR) based antenna test chamber. It is carefully designed to eliminate ghost targets within the chamber during target simulation tests and includes a highly accurate positioner for angular measurements.

The new R&S ARC-TEMP temperature test option creates a temperature-controlled enviroment for the radar under test and supports a wide range from -40 °C to +85 °C. The heated or cooled air is provided by an external thermal air stream system that supplies the air to the temperature bubble mounted on the positioner. This changes the temperature without affecting the chamber’s measurement performance. This feature makes it possible to automate measurements at different temperatures without a separate climatic chamber, which increases radar testing speed.

In addition, the new R&S ARC-FX90 universal feed antenna, which supports 60 GHz to 90 GHz, can be added to the R&S ATC1500C. The antenna includes an orthomode transducer, which enables parallel access to vertical and horizontal polarizations.

With these new options for the R&S ATS1500C, developers can efficiently characterize RF transmitters, calibrate antenna manifolds, measure antenna patterns, test robustness against interference, check compliance with regulations such as ETSI and FCC as well as plan testing and calibration procedures for later mass production. The R&S ATS1500C is used as a reference environment before porting the procedures to a production tester.

In combination with the R&S AREG800A automotive radar echo generator, the R&S ATS1500C is the most complete system on the market for automotive radar module development, validation, calibration and compliance testing.

The new R&S ARC-FX90 universal feed will be available at the end of 2022 and the R&S ARC-TEMP temperature option in Q1 2023. Both options are hardware extensions to the R&S ATS1500C and can be retrofitted.

Über die Rohde & Schwarz GmbH & Co. KG

The Rohde & Schwarz technology group is among the trailblazers when it comes to paving the way for a safer and connected world with its leading solutions in test & measurement, technology systems, and networks & cybersecurity. Founded more than 85 years ago, the group is a reliable partner for industry and government customers around the globe. On June 30, 2021, Rohde & Schwarz had around 13,000 employees worldwide. The independent group achieved a net revenue of EUR 2.28 billion in the 2020/2021 fiscal year (July to June). The company is headquartered in Munich, Germany.

Automotive test solutions – Test it. Trust it.
As a leading worldwide provider of test and measurement software, instruments and systems, Rohde & Schwarz employs its technical expertise to develop innovative solutions for the entire automotive lifecycle from predevelopment to production. OEMs, tier 1s, chip suppliers and engineering service providers around the world rely on the company’s proven test solutions for automotive radar, connectivity, infotainment, high-performance computing and EMC compliance. With innovative solutions for radar tests in development, integration and production, Rohde & Schwarz supports its customers as a reliable partner for the launch of next-generation ADAS and AD systems. The company’s many years of experience and expertise in wireless communications ensure robust connectivity conforming to all standards from 5G and C-V2X to UWB, Wi-Fi and GNSS. Rohde & Schwarz instruments enable the development and debugging of in-vehicle networks with leading-edge bus speeds as well as ECUs such as high-performance domain controllers, and help to eliminate EMC issues. Rohde & Schwarz also offers T&M equipment and custom turnkey test systems for carrying out EMI and EMS measurements on vehicles and vehicle components in line with all major CISPR, ISO and manufacturer-specific EMC standards. These systems and equipment support full vehicle antenna testing and wireless coexistence testing with the user’s own systems and instruments. The company also offers outstanding solutions for component and board level tests during ECU production. Partners and customers around the world use these test solutions to ensure automotive components and systems function correctly, interact flawlessly and smoothly and communicate faultlessly with the outside world.
